Permanent deformation estimates of dynamic equipment foundations: Application to a gas turbine in granular soils

Resumen

Permanent displacements of a gas turbine founded on a fine, poorly graded, and medium density sand are studied. The amplitudes and modes of vibration are computed using Barkan´s formulation, and the “High-Cycle Accumulation” (HCA) model is employed to account for accumulated deformations due to the high number of cycles. The methodology is simple: it can be easily incorporated into standard mathematical software, and HCA model parameters can be estimated based on granulometry and index properties. Special attention is devoted to ‘transient’ situations at equipment´s start-up, during which a range of frequencies – including frequencies that could be similar to the natural frequencies of the ground – is traversed. Results show that such transient situations could be more restrictive than stationary situations corresponding to normal operation. Therefore, checking the stationary situation only might not be enough, and studying the influence of transient situations on computed permanent displacements is needed to produce a proper foundation design
