Ka Band active array antenna for mobile satellite communications
Cita
Sierra Castañer, Manuel
ORCID: https://orcid.org/0000-0002-8752-6448, Fernández González, José Manuel ORCID: https://orcid.org/0000-0002-9296-4098, Sierra Pérez, Manuel ORCID: https://orcid.org/0000-0002-8297-986X, Tamayo Domínguez, Adrián ORCID: https://orcid.org/0000-0002-2322-3800 and Muriel Barrado, Alfonso Tomás ORCID: https://orcid.org/0000-0001-8560-5110
(2016).
Ka Band active array antenna for mobile satellite communications.
En: "International Symposium on Antennas and Propagation (ISAP2016)", 24/10/2016 - 28/10/2016, Okinawa, Japan. pp. 1-2.
ORCID: https://orcid.org/0000-0002-8752-6448, Fernández González, José Manuel ORCID: https://orcid.org/0000-0002-9296-4098, Sierra Pérez, Manuel ORCID: https://orcid.org/0000-0002-8297-986X, Tamayo Domínguez, Adrián ORCID: https://orcid.org/0000-0002-2322-3800 and Muriel Barrado, Alfonso Tomás ORCID: https://orcid.org/0000-0001-8560-5110
(2016).
Ka Band active array antenna for mobile satellite communications.
En: "International Symposium on Antennas and Propagation (ISAP2016)", 24/10/2016 - 28/10/2016, Okinawa, Japan. pp. 1-2.
Descripción
| Título: | Ka Band active array antenna for mobile satellite communications |
|---|---|
| Autor/es: |
|
| Tipo de Documento: | Ponencia en Congreso o Jornada (Artículo) |
| Título del Evento: | International Symposium on Antennas and Propagation (ISAP2016) |
| Fechas del Evento: | 24/10/2016 - 28/10/2016 |
| Lugar del Evento: | Okinawa, Japan |
| Título del Libro: | International Symposium on Antennas and Propagation (ISAP2016) |
| Fecha: | 2016 |
| Materias: | |
| ODS: | |
| Palabras Clave Informales: | Phased Array Antennas, Ka Band, Satellite Communications |
| Escuela: | E.T.S.I. Telecomunicación (UPM) |
| Departamento: | Señales, Sistemas y Radiocomunicaciones |
| Licencias Creative Commons: | Reconocimiento - Sin obra derivada - No comercial |
Resumen
This paper describes a modular active antenna for
satellite communications in the K/Ka band. The application is thought for mobile satellite communications and internet links, mainly for commercial airplanes. The impossibility to build full active antennas, including amplifiers in all the elements, leads
to a modular semi active antenna. Here the module is a small subarray with complete phase control in the elements. The phase control is made with ad-hoc phase shifters giving the minimum losses. Only two-bit control has been selected to perform phase shifters associated to a circular polarization radiating element. The feeding network has been selected to minimise the losses and the gap waveguide has been designed to perform the network. The radiating element is a circular double patch fed into two points to obtain circular polarization.
The entire prototype has been designed in LTCC substrate to minimise the losses and stabilise the structure.
